十二、高扭矩碟形弹簧垫圈规格(使用温度-200℃—330℃)
|
 |
 |
|
 |
|
| 发布时间：2008.04.29 新闻来源：www.discspringsource.cn 浏览次数： |
| |
|
序号 |
工程螺栓尺寸 |
D/mm ±１％ |
d/mm±１％ |
t/mm±１％ |
H0/mm±１％ |
建议予紧扭矩 P/N.m |
|
SY1401 |
M8 |
15.0 |
8.40 |
1.50 |
1.7 |
22 |
|
SY1402 |
M10 |
19.00 |
10.50 |
2.00 |
2.25 |
35 |
|
SY1403 |
M12 |
22.00 |
12.50 |
2.5 |
2.75 |
50 |
|
SY1404 |
M14 |
26.00 |
14.50 |
2.50 |
2.80 |
70 |
|
SY1405 |
M16 |
30.00 |
16.80 |
3.00 |
3.40 |
110 |
|
SY1406 |
M18 |
34.00 |
18.80 |
3.50 |
3.45 |
140 |
|
SY1407 |
M20 |
38.00 |
20.80 |
4.00 |
4.45 |
220 |
|
SY1408 |
M22 |
42.00 |
22.80 |
4.00 |
4.55 |
300 |
|
SY1409 |
M24 |
46.00 |
24.80 |
4.50 |
5.1 |
390 |
|
SY1410 |
M27 |
52.00 |
27.80 |
4.50 |
5.2 |
550 |
|
SY1411 |
M30 |
56.00 |
30.80 |
5.00 |
5.75 |
650 |
|
SY1412 |
M32 |
60.00 |
32.80 |
5.00 |
5.85 |
750 |
|
SY1413 |
M36 |
68.00 |
36.80 |
6.00 |
6.90 |
960 |
|
SY1414 |
M38 |
72.00 |
38.80 |
6.00 |
7.30 |
1550 |
|
SY1415 |
M39 |
76.00 |
39.80 |
6.00 |
7.40 |
2260 |
|
SY1416 |
M42 |
80.00 |
43.00 |
6.00 |
7.70 |
3120 |
|
SY1417 |
M46 |
86.00 |
46.80 |
7.00 |
8.30 |
4270 |
|
SY1418 |
M48 |
92.00 |
49.00 |
8.00 |
9.50 |
5970 |
|
SY1419 |
M52 |
98.00 |
53.00 |
8.00 |
9.80 |
6900 |
|
SY1420 |
M56 |
112.00 |
57.00 |
8.00 |
9.80 |
7600 |
|
SY1421 |
M60 |
115.00 |
61.50 |
8.00 |
9.80 |
8300 |
|
SY1422 |
M64 |
120.00 |
65.50 |
9.00 |
11.00 |
9350 |
|
SY1423 |
M72 |
128.00 |
73.50 |
11.00 |
13.00 |
9530 |
|
SY1424 |
M82 |
156.00 |
83.50 |
13.00 |
15.50 |
10020 | |
| |
|
